DENAFRIPS TERMINATOR PLUS New Flagship - Hi Fi Redefined

DENAFRIPS TERMINATOR DAC NOW UPGRADED

TERMINATOR INFO

Technical Highlights

  • Proprietary R2R + DSD Architecture
  • True balanced 26BIT R2R + 6BIT DSD (32 steps FIR Filters)
  • Native DSD decoding with 0.005% precision resistors
  • Encapsulated Flagship Ultra Low Noise Power Supply
  • CRYSTEK Flagship CCHD-957 Femto Clocks
  • Adaptive FIFO Buffer Reclocking
  • New Improved Digital Signal Processing FPGA Code
  • DSD1024, PCM1536 Supports On USB & I²S Input
  • Proprietary USB Audio Solution via STM32F446 Advanced AMR Based MCU
  • Licensed Thesycon USB Driver For Windows Platform
  • Driverless On Mac & Linux
  • Dual AES/EBU Input Supports
  • Sharp/Slow Filters Option
  • I²S Pinout Configuration
  • I²S DSD Channel Swap Configuration



DSD

  • DSD64-DoP On All Input
  • DSD1024 On USB & I²S Input Only



PCM

  • 24bits / 44.1, 48, 88.2, 96, 176.4, 192KHz On All Input
  • 1536kHz On USB & I²S Input



Sampling Mode: Non-Oversampling NOS / Oversampling OS



Digital Input

  • Coax 1 via RCA
  • Coax 2 via BNC 75 Ω
  • TOSLink x 1
  • AES/EBU x 2
  • USB
  • I²S via HDMI LVDS
  • I²S via RJ45 LVDS
  • I²S via RJ45 LVCMOS



Analog Output

  • RCA at 2.3Vrms, 625 Ω
  • XLR at 4.6Vrms, 1250 Ω



Frequency Response: 20-40KHz -0.2dB

THD+N: 0.0010%

S/N Ratio: 124dB

Dynamic Range: >132dB

Stereo Crosstalk: -110dB



AC Power Requirement: 100-240VAC, 50/60Hz (Worldwide Voltage)

Power Consumption: ≤20W

Dimension: 430 x 380 x 105 mm

Package Dim: 610 x 570 x 275 mm

Package Content: DAC only. No power cord & remote control.

Weight: 19.0 Kg

Color: Silver / Black



Warranty: 36 Months

DENAFRIPS VENUS DAC

VENUS INFO

Technical Highlights

  • Proprietary R2R + DSD Architecture
  • True balanced 26BIT R2R + 6BIT DSD (32 steps FIR Filters)
  • Native DSD decoding with 0.005% precision resistors
  • Encapsulated Premium Ultra Low Noise Power Supply
  • TCXO – Temperature-Compensated Crystal Oscillator
  • Adaptive FIFO Buffer Reclocking
  • New Improved Digital Signal Processing FPGA Code
  • DSD1024, PCM1536 Supports On USB & I²S Input
  • Proprietary USB Audio Solution via STM32F446 Advanced AMR Based MCU
  • Licensed Thesycon USB Driver For Windows Platform
  • Driverless On Mac & Linux
  • Dual AES/EBU Input Supports
  • Sharp/Slow Filters Option
  • I²S Pinout Configuration
  • I²S DSD Channel Swap Configuration



DSD

  • DSD64-DoP On All Input
  • DSD1024 On USB & I²S Input Only

PCM

  • 24bits / 44.1, 48, 88.2, 96, 176.4, 192KHz On All Input
  • 1536kHz On USB & I²S Input



Sampling Mode: Non-Oversampling NOS / Oversampling OS



Digital Input

  • Coax 1 via RCA
  • Coax 2 via BNC 75 Ω
  • TOSLink x 1
  • AES/EBU x 2
  • USB
  • I²S via HDMI LVDS



Analog Output

  • RCA at 2.2Vrms, 625 Ω
  • XLR at 4.4Vrms, 1250 Ω



Frequency Response: 20-70KHz -3dB

THD+N: 0.0020%

S/N Ratio: 120dB

Dynamic Range: >121dB

Stereo Crosstalk: -110dB



AC Power Requirement: 100-240VAC, 50/60Hz (Worldwide Voltage)

Power Consumption: ≤20W

Dimension: 320 x 330 x 110 mm (Including feet)

Package Dim: 470 x 440 x 175 mm

Package Content: DAC only. No power cord & remote control.

Weight: 8.5 Kg

Color: Silver / Black



Warranty: 36 Months

DENAFRIPS PONTUS DAC

PONTUS INFO

Technical Highlights

  • Proprietary R2R + DSD Architecture
  • True balanced 24BIT R2R + 6BIT DSD (32 steps FIR Filters)
  • Native DSD decoding with 0.01% precision resistors
  • Encapsulated Ultra Low Noise Power Supply
  • Amanero USB Interface
  • Ultra Low Jitter Digital Receiver AK4118
  • Adaptive FIFO Buffer Reclocking

DSD

  • 2.8224MHz(DSD1X) On All Input
  • 5.6448MHz(DSD2X), 11.288MHz(DSD4X) On USB & I²S Input Only

PCM

  • 24bits / 44.1, 48, 88.2, 96, 176.4, 192KHz On All Input
  • 24bits / 352.8, 384kHz On USB & I²S Input Only

Sampling Mode: Non-Oversampling NOS / Oversampling OS

Digital Input

  • Coax 1 via RCA
  • Coax 2 via BNC 75 Ω
  • TOSLink x 1
  • AES/EBU x 2
  • USB
  • I²S via HDMI LVDS / RJ45 LVCMOS

Analog Output

  • RCA at 2.2Vrms, 625 Ω
  • XLR at 4.4Vrms, 1250 Ω

Frequency Response: 20-70KHz -3dB

THD+N: 0.0025%

S/N Ratio: 120dB

Dynamic Range: >121dB

Stereo Crosstalk: -110dB

AC Power Requirement: 110-240VAC, 50/60Hz (Worldwide Voltage)

Power Consumption: ≤20W

Dimension: 320 x 330 x 80 mm

Package Dim: 470 x 440 x 175 mm

Weight: 8.5 Kg

Color: Silver / Black

Warranty: 36 Months

DENAFRIPS ARES II DAC

ARES II INFO

Technical Highlights

  • Proprietary R2R + DSD Architecture
  • True balanced 20BIT R2R + 6BIT DSD (32 steps FIR Filters)
  • Native DSD decoding with 0.01% precision resistors
  • Low Noise Power Supply
  • FIFO Buffer
  • Digital Signal Processing via FPGA
  • DSD1024, PCM1536 Supports On USB Input
  • Proprietary USB Audio Solution via STM32F446 Advanced AMR Based MCU
  • Licensed Thesycon USB Driver For Windows Platform
  • Driverless On Mac & Linux

DSD

  • DSD64-DoP On All Input
  • DSD1024 On USB Input Only

PCM

  • 24bits / 44.1, 48, 88.2, 96, 176.4, 192KHz On All Input
  • 1536kHz On USB Input

Sampling Mode: Oversampling OS / Non-Oversampling NOS

Digital Input

  • Coax x 2
  • TOSLink x 2
  • USB

Analog Output

  • RCA at 2.2Vrms, 625 Ω
  • XLR at 4.4Vrms, 1250 Ω

Frequency Response: 20-70KHz -3dB

THD+N: 0.004%

S/N Ratio: 115dB

Dynamic Range: >119dB

Stereo Crosstalk: -124dB

AC Power Requirement: 110/240VAC, 50/60Hz

Power Consumption: ≤20W

Dimension: 215 x 230 x 45 mm

Package Dim: 375 x 330 x 115 mm

Weight: 3.5 Kg

Color: Black

Warranty: 36 Months

Product Launch: ARES II

Hello guys,

We’re happy to announce the tiny mighty ARES was upgraded to ARES II. The DSP portion of the ARES II shared much similarity to the Terminator DSP board launched recently, of which received high-praises all over the world!

Key Highlights:

  • Digital Signal Processing via FPGA instead of CPLD
  • DSD1024, PCM1536 Supports On USB Input
  • Proprietary USB Audio Solution via STM32F446 Advanced AMR Based MCU
  • Licensed Thesycon USB Driver For Windows Platform
  • Driver-less On Mac & Linux
  • Sampling Mode: NOS / OS
  • Filter Selection: Slow / Sharp



* Massive O-Core transformer, over 70pcs of capacitors farm.

* Six (6) sets of Linear Technology LDO Voltage Regulators

* True Balanced, 0.01% Precision Matched Resistors Array

* All New DSP FPGA & USB Audio Interface Solution

DENAFRIPS HESTIA PRE AMP

HESTIA PRE AMP INFO

Technical Highlights

  • Pure Class-A, True Balanced, Fully Discrete Line Stage
  • 85 Steps Microprocessor Controlled Relay Based Stepped Attenuator
  • Precision Matched Resistors & Components with Perfect Channel Balance And Low Distortion
  • Remote Controlled

Input

  • IN1 – XLR
  • IN2 – XLR
  • IN3 – RCA​​​​​​​

Output

  • RCA at 2.0Vrms
  • XLR at 4.0Vrms

Frequency Response: 10-80kHz（-0.3dB）

THD+N: 0.00023%

S/N Ratio: 120dB

Dynamic Range: >121dB

Stereo Crosstalk: -110dB

Input Impedance: 20k Ω

Output Impedance: 200 Ω

AC Power Requirement: 110/240VAC, 50/60Hz

Power Consumption: 1W (Idle), 20W (Operational)

Dimension: 320W x 330D x 60H mm

Weight: 6.5 Kg

Color: Black/Silver

Warranty: 36 Months

DENAFRIPS HYPERION POWER AMP

HYPERION POWER AMP INFO

Technical Highlights

  • Class-AB, True Balanced, Fully Discrete Power Amp

Input

  • XLR

Output

  • 4mm Speaker Binding Post

Gain: 28dB

Output Power: 80w RMS per channel into 8ohms

Frequency Response: 10-80kHz（-2.2dB）

THD+N: 0.00078%

S/N Ratio: 125dB

Dynamic Range: >121dB

Stereo Crosstalk: -110dB

AC Power Requirement: 110/240VAC, 50/60Hz

Power Consumption: 35W (Idle), 234W (Operational)

Dimension: 320W x 380D x 100H mm

Weight: 16.5 Kg

Color: Black/Silver

Warranty: 36 Months
